6.7 Image Characteristics
Figure 7.1 shows an image of a point source obtained in ground testing. A 2-dimensional Gaussian fit to this PSF has the following characteristics:
FWHM (x-direction): 2.47 pixels = 58.1 mas
FWHM (y direction): 2.29 pixels = 53.8 mas
Fraction of light in brightest pixel: 10.1%.
Figure 6.1: Two-dimensional PSF for COS.
|
